KNECHT B 500 - Description of the Assemblies

19
3. Description
3.4 Description of the assemblies
1 Belt protecting hood
2 Belt release lever
3 Hand wheel for height adjustment of “left polishing unit”
4 Rear doors of polishing units (concealed)
5 Control panel
6 Switch cabinet
7 Pneumatic cabinet
8 Hand wheel for height adjustment of “right polishing unit”
9 Protective hood
10 Water tray
11 Adjustable machine feet
Figure 3-2 General view of the grinding machine
3
2
5
6
7
4
1
9
8
11
10
