10
1.5 Figure and item numbers in the operating instructions
If the text refers to a machine component shown in a figure, then a figure or item number is
added in brackets after the machine component.
Example: (7-5/1) denotes figure number 7-5, item 1.
Adjusting the grinding angle with the hand wheel
(7-5/1).
The grinding angle can be read off the scale
(7-5/2).
1. Important notes
Figure 7-5 Adjusting the grinding angle
1
2
