User manual - DATA RECORDER and cooperating software
Register Write Range Register description
18h No 0÷6 Days of the week registry
19h Yes
2000÷2099
Year registry
1Ah Yes 1÷12 Months registry
1Bh Yes 1÷31 Days registry
1Ch Yes 0÷23 Hours registry
1Dh Yes 0÷59 Minutes registry
1Eh Yes 0÷59 Seconds registry
1Fh Yes 0÷3
Control registry for time-related settings:
0
- starting continuous updating of registries 18h ÷ 1Eh by the internal
clock (current time and date),
80h
- stopping continuous updating of registries 18h ÷ 1Eh by the
internal clock (automatically after writing one of 18h ÷ 1Eh registries).
In this status 18h ÷ 1Eh registries can be written with new values in
order to update internal clock settings. Updating the clock settings
with contents of 18h ÷ 1Eh registries can be executed by sending the
following commands to the control registry:
1
- hour update on the basis of (1Ch ÷ 1Eh) registries’ contents;
2
- date update on the basis of (18h ÷ 1Bh) registries’ contents;
3
- time and date update on the basis of (18h ÷ 1Eh) registries’
contents.
After sending commands
1
,
2
or
3
the contents of registries
automatically return to 0.
20h
2
Yes 0÷199 Address of device
21h No see descr.
Device identification code
Voltage-current inputs version: 5Dh
TC/RTD inputs version: 67h
22h
3
Yes 0÷7
“
Baud rate
” parameter in “
RS485 port settings
” menu (baud rate):
0
- 1200;
1
- 2400;
2
- 4800;
3
- 9600;
4
- 19200;
5
- 38400;
6
- 57600;
7
- 115200;
23h
4
Yes 0÷1
“
Conf. change
” parameter in “
RS485 port settings
” menu
(permission to write registers):
0
- write denied;
1
- write allowed.
28h No Firmware version
29h No Compilation number
2Ah No Higher (2
nd
) word of serial number
2Bh No Lower (1
st
) word of serial number
2Ch No 1, 4, 8 Number of units’ measurement channels
2Dh No Size of unit’s memory for recording in kB.
30h Yes 0÷255
Activation of logging for selected channel (binary):
00000000
hgfedcba
(
h
– channel no 8,
a
– channel no 1):
0
– logging On;
1
– logging Off.
31h Yes 0÷2
“
Triggering
” parameter in “
Logging setup
” submenu:
0
- always;
1
- hi level,
2
- lo level
