Register Write Range Register description
32h Yes 0÷14
“
Rec. period
” parameter in "
Logging setup
" submenu:
0
- 1 sec.;
1
- 2 sec.;
2
- 5 sec.;
3
- 10 sec.;
4
- 15 sec.;
5
- 20 sec.;
6
- 30 sec.;
7
- 1 min.;
8
- 2 min.;
9
- 5 min.;
10
- 10 min.;
11
- 15 min.;
12
- 20 sek.;
13
- 30 min.;
14
- 60 min.
33h Yes 0÷1
“
Write
” parameter in "
Logging setup
" submenu:
0
- until full;
1
- cyclic
34h Yes 0÷255
Activation of averaging for selected channel (binary):
00000000
hgfedcba
(
h
- channel no 8,
a
- channel no 1):
0
- averaging off;
1
- averaging on;
38h No Written memory in kB
39h No
Approximated time remaining until memory is filled with recorded
measurement results – Higher (2
nd
) byte (parameter in seconds).
3Ah No
Approximated time remaining until memory is filled with recorded
measurement results – Lower (1
st
) byte (parameter in seconds).
Configuration parameters for channel No. 1 (
U/I version
)
40h Yes 0÷6
“
Input type
” parameter in “
Inputs settings
” submenu for channel 1:
0
- inactive;
1
- 0-20 mA;
2
- 4-20 mA;
3
- 0-5 V;
4
- 1-5 V;
5
- 0-10 V;
6
- 2-10 V
41h Yes -9999÷9999
“
Lo value
” parameter in “
Inputs settings
” submenu for channel 1
(not considering decimal point)
42h Yes -9999÷9999
“
Hi value
” parameter in “
Inputs settings
” submenu for channel 1 (not
considering decimal point)
43h Yes 0÷3
“
Dec. point
” parameter in “
Inputs settings
” submenu for
channel1:
0
- 0;
1
- 0,0;
2
- 0,00;
3
- 0,000
44h Yes 0÷5
“
Filter
” parameter in “
Inputs settings
” submenu for channel 1:
(filtration coefficient)
45h Yes 0÷399
“
Lower ext.
” parameter in “
Inputs settings
” submenu for channel 1
expressed in 0.01 mA (not considering decimal point)
46h Yes 0÷199
“
Upper ext.
” parameter in “
Inputs settings
” submenu for channel 1
expressed in 0.01 mA (not considering decimal point)
Configuration parameters for channel No. 1 ( mV/
RTD/TC version
)
40h Yes 0÷15
“
Input type
” parameter in “
Inputs settings
” submenu for channel 1:
0
- inactive;
1
– 60 mV;
2
- 75 mV;
3
– 100 mV;
4
– 150 mV;
5
–
PT100;
6
– PT500;
7
– PT1000;
8
– Tc – K;
9
– Tc – S;
10
– Tc – J;
11
– Tc – T;
12
– Tc – N;
13
– Tc – R;
14
– Tc – B;
15
– Tc – E
41h Yes -9999÷9999
“
Lo value
” parameter in “
Inputs settings
” submenu for channel 1
expressed by 0,1°C or °F (not considering decimal point)
42h Yes -9999÷9999
“
Hi value
” parameter in “
Inputs settings
” submenu for channel 1
expressed by 0,1°C or °F (not considering decimal point)
43h Yes
see
descriprion
“
Dec. point
” parameter in “
Inputs settings
” submenu for
channel 1, for RTD/TC input:
0
– 0;
1
– 0.0;
2
– 0.00;
3
– 0.000, for mV
input constant value:
1
-0.0
7
