Register Write Range Register description
44h Yes 0÷5
“
Filter
” parameter in “
Inputs settings
” submenu for channel 1:
(filtration coefficient)
45h Yes 0÷99
“
Lower ext.
” parameter in “
Inputs settings
” submenu for channel 1
expressed in 0.1 mV (not considering decimal point)
46h Yes 0÷199
“
Upper ext.
” parameter in “
Inputs settings
” submenu for channel 1
expressed in 0.1 mV (not considering decimal point)
4Eh Yes 0÷1
“
Unit
” parameter in “
Inputs settings
” submenu for channel 1: 0=°C,
1=°F; only for RTD/TC inputs
4Fh Yes -99÷99
“
Bias
” parameter in “
Inputs settings
” submenu for channel 1
expressed in 0,1°C or °F; only for RTD/TC inputs
140h Yes 1÷2
“
Connection type
” parameter in “
Inputs settings
” submenu for
channel 1:
1
– 3-wire connection;
2
– 2-wire connection; only for RTD
inputs
Configuration parameters for channel No. 1 (common)
47h Yes Character
“
Name
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 1; Lower byte – character No. 2
48h Yes Character
“
Name
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 3; Lower byte – character No. 4
49h Yes Character
“
Name
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 5; Lower byte – character No. 6
4Ah Yes Character
“
Name
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 7; Lower byte – character No. 8
4Bh Yes Character
“
Name
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 9; Lower byte – 0
4Ch Yes Character
“
Unit
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 1; Lower byte – character No. 2
4Dh Yes Character
“
Unit
” parameter in “
Inputs settings
” submenu for channel 1;
Higher byte – character No. 3; Lower byte – character No. 4
Register from 50h to 5Fh and
150h
Parameters in “
Inputs settings
” submenu for channel 2; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
Register from 60h to 6Fh and
160h
Parameters in “
Inputs settings
” submenu for channel 3; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
Register from 70h to 7Fh and
170h
Parameters in “
Inputs settings
” submenu for channel 4; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
Register from 80h to 8Fh and
180h
Parameters in “
Inputs settings
” submenu for channel 5; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
Register from 90h to 9Fh and
190h
Parameters in “
Inputs settings
” submenu for channel 6; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
Register from A0h to AFh and
1A0h
Parameters in “
Inputs settings
” submenu for channel 7; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
Register from B0h to BFh and
1B0h
Parameters in “
Inputs settings
” submenu for channel 8; registry
description like for channel 1 (see registers 40h to 4Dh and 140h).
