Kobold ZLS-2 - Page 73

User manual - DATA RECORDER and cooperating software
Register Write Range Register description
Alarm configuration parameters for channel No. 1
C0h Yes 0÷1
"
AL1 mode
" parameter in “
Inputs settings
” submenu for channel 1;
0
– under threshold;
1
– over threshold
C1h Yes -9999÷9999
"
Threshold 1
" parameter in “
Inputs settings
” submenu
for channel 1;
C2h Yes -9999÷9999
"
Hysteresis 1
" parameter in “
Inputs settings
” submenu
for channel 1;
C3h Yes 0÷1
"
AL2 mode
" parameter in “
Inputs settings
” submenu for channel 1;
0
– under threshold;
1
– over threshold
C4h Yes -9999÷9999
"
Threshold 2
" parameter in “
Inputs settings
” submenu
for channel 1;
C5h Yes -9999÷9999
"
Hysteresis 2
" parameter in “
Inputs settings
” submenu
for channel 1;
Register from C8h to CDh
Alarm parameters in “
Inputs settings
” submenu for channel 2;
registry description like for channel 1 (see registers C0h to C5h).
Register from D0h to D5h
Alarm parameters in “
Inputs settings
” submenu for channel 3;
registry description like for channel 1 (see registers C0h to C5h).
Register from D8h to DDh
Alarm parameters in “
Inputs settings
” submenu for channel 4;
registry description like for channel 1 (see registers C0h to C5h).
Register from E0h to E5h
Alarm parameters in “
Inputs settings
” submenu for channel 5;
registry description like for channel 1 (see registers C0h to C5h).
Register from E8h to EDh
Alarm parameters in “
Inputs settings
” submenu for channel 6;
registry description like for channel 1 (see registers C0h to C5h).
Register from F0h to F5h
Alarm parameters in “
Inputs settings
” submenu for channel 7;
registry description like for channel 1 (see registers C0h to C5h).
Register from F8h to FDh
Alarm parameters in “
Inputs settings
” submenu for channel 8;
registry description like for channel 1 (see registers C0h to C5h).
Configuration parameters for output No. 1
100h Yes 0÷2
“
Mode
” parameter in “
Outputs settings
” submenu for output 1;
0
– inactive (always OPEN)
1
– normally OPEN (N.O.)
2
– normally CLOSED (N.C.)
101h Yes 0÷1
“
Logic func.
” parameter in “
Outputs settings
” submenu for output 1;
0
–
OR
;
1
–
AND
102h Yes 0÷4
“
Channel 1
” parameter in “
Outputs settings:source
” submenu for
output 1;
0
–
inactive
1
–
alarm 1
2 – alarm 2
3 – alarm 1 or 2
4 – alarm 1 and 2
103h Yes 0÷4
“
Channel 2
” parameter in “
Outputs settings:source
” submenu for
output 1; registry description like for “
Channel 1
” (see register 102h).
