User manual - DATA RECORDER and cooperating software
Parameter Description Value
Description
page
Filter Level of filtration of indications 52
Bias Shifting of measurement scale 57
Upper ext. Upper extension of measurement range 54
Lower ext. Lower extension of measurement range 54
AL1 mode Alarm 1 generation mode 52
Threshold 1 Threshold of alarm 1 52
Hysteresis 1 Hysteresis of alarm 1 52
AL2 mode Alarm 2 generation mode 52
Threshold 2 Threshold of alarm 2 52
Hysteresis 2 Hysteresis of alarm 2 52
Output 1 settings in submenu ”Outputs settings”
Mode Output mode 57
Logic funct. Logic function mode 57
Source: channel 1 Channel 1 alarmstate source 57
Source: channel 2 Channel 2 alarm state source 57
Source: channel 3 Channel 3 alarm state source 57
Source: channel 4 Channel 4 alarm state source 57
Source: channel 5 Channel 5 alarm-state source 57
Source: channel 6 Channel 6 alarm-state source 57
Source: channel 7 Channel 7 alarm-state source 57
Source: channel 8 Channel 8 alarm-state source 57
Close delay Close switch delay time 58
Open delay Open switch delay time 58
Closed hold time Time for holding the closed state 58
Open hold time Time for holding the open state 58
Output 2 settings in submenu ”Outputs settings”
Mode Output mode 57
Logic funct. Logic function mode 57
Source: channel 1 Channel 1 alarm state source 57
Source: channel 2 Channel 2 alarm state source 57
Source: channel 3 Channel 3 alarm state source 57
Source: channel 4 Channel 4 alarm state source 57
Source: channel 5 Channel 5 alarm state source 57
Source: channel 6 Channel 6 alarm state source 57
