8.5.1 Keypad operation
The two keys can be used to perform the following functions:
Key symbol Functions
press once : move up one menu item, increase number by one
press twice in rapid succession : increase number by ten
press once : decrease number by one
press twice in rapid succession : decrease number by ten
hold right key pressed, and then press left key as well :
to enter a number, “Return” function
8.5.2 Status display
8.5.3 Standard menu
120 S701x2-S724x2 Instructions Manual
Setup 07/2014 Kollmorgen
ð p.119
