Kollmorgen S7240

4.3 Part number scheme
The part number is identical with the order code.
24 S701x2-S724x2 Instructions Manual
Package 07/2014 Kollmorgen
Family
S7 S700
Voltage Rating
0 208...480V
6 110...230V
Current Rating
01 1.5 Arms
03 3 Arms
06 6 Arms
12 12 Arms
24 24 Arms
48
3
48 Arms
72
3
72 Arms
Electrical/mechanical Options
2 standard
F standard and coated PCBs
12A and 24A rated current only:
S extended Ipeak
H extended Ipeak and
coated PCBs
Expansion Cards Slot 3
NA no expansion card in slot 3,
EtherCAT&CANopen onboard
F2 Fan controller
PM PosI/O
PA PosI/O-Monitor
S3
3
Safety card S1-2, SIL CL3
S4
3
Safety card S2-2, SIL CL2
Firmware Options
NA no option
(EtherCAT&CANopen)
S7060 2 -EIF2 PM -NA
1
- 000
2
Expansion Cards Slot 1
NA no expansion card in Slot 1,
EtherCAT&CANopen onboard
2C 2CAN module mounted
DN DEVICENET
PB PROFIBUS
SE SERCOS II
SN SYNQNET
EI I/O Extension
FB FB-2to1
Expansion Cards Slot 2
NA no expansion card in Slot 2,
EtherCAT&CANopen onboard
F2 Fan controller
PM PosI/O
PA PosI/O-Monitor
1 is void with standard
2 additional coding defines customer specific specials.
3 described in seperate documentation
Example 1: S70602-EIF2PM-NA-000
S7 S700
06 6A rated current
0 208...480V rated voltage
2 no electr./mech. option
EI I/O expansion card in Slot 1
F2 Expansion card Controlled Fan in Slot 2
PM PosI/O expansion card in Slot 3
NA Standard (EtherCAT&CANopen onboard)
000 no customer specific specials
Example 2: S7126S-EIF2S4-NA-000
S7 S700
12 12A rated current
6 110...230V rated voltage
S extended Ipeak (30A)
EI I/O Erweiterungskarte in Slot 1
F2 Expansion card Controlled Fan in Slot 2
S4 Safety Card S2-2 in Slot 3
NA Standard (EtherCAT&CANopen onboard)
000 no customer specific specials
