Technical data S7xx6:
Brake circuit Supply voltage
Type Rated data DIM 110 V 230 V
S70162
Switch-on threshold of brake circuit V 200 400
Overvoltage F02 V 235 455
Internal brake resistor (RBi) Ohm 33
Continuous power internal brake resistor (RBi) W 50
Max. brake power (average for 1s) kW 0,9
Pulse brake power kW 1,2 4
External brake resistor (RBe), optional Ohm 33*
Continuous brake power external (RBe) kW 0,3
S70362
Switch-on threshold of brake circuit V 200 400
Overvoltage F02 V 235 455
Internal brake resistor (RBi) Ohm 33
Continuous power internal brake resistor (RBi) W 50
Max. brake power (average for 1s) kW 0,9
Pulse brake power kW 1,2 4
External brake resistor (RBe), optional Ohm 33*
Continuous brake power external (RBe) kW 1
S70662
Switch-on threshold of brake circuit V 200 400
Overvoltage F02 V 235 455
Internal brake resistor (RBi) Ohm 33
Continuous power internal brake resistor (RBi) W 75
Max. brake power (average for 1s) kW 1,38
Pulse brake power kW 1,2 4
External brake resistor (RBe), optional Ohm 33*
Continuous brake power external (RBe) kW 1
S71262/S7126S
Switch-on threshold of brake circuit V 200 400
Overvoltage F02 V 235 455
Internal brake resistor (RBi) Ohm 33
Continuous power internal brake resistor (RBi) W 100
Max. brake power (average for 1s) kW 1,93
Pulse brake power kW 1,2 4
External brake resistor (RBe), optional Ohm 33*
Continuous brake power external (RBe) kW 1,5
S72462/S7246S
Switch-on threshold of brake circuit V 200 400
Overvoltage F02 V 235 455
Internal brake resistor (RBi) Ohm 23
Continuous power internal brake resistor (RBi) W 200
Max. brake power (average for 1s) kW 3,93
Pulse brake power kW 1,74 6
External brake resistor (RBe), optional Ohm 23*
Continuous brake power external (RBe) kW 4
* Can be reduced to 15 Ohm (PBALRES 15) if required.
Suitable external brake resistors can be found in our accessories manual.
S701x2-S724x2 Instructions Manual 35
Kollmorgen 07/2014 Technical description
