SECTION 3 - PARTS, ASSEMBLIES & HARDWARE
1-3-1
3-1
© 2018 Konami Gaming Inc. P/N 810352
CONCERTO CRESCENT
(Original Instructions)
SECTION 3
Parts, Assemblies & Hardware
LCD
LED Light
Panel
Subwoofer
(located
behind LCD)
Speakers
(located on
deck door)
Player Tracking
Panel (located
on main deck
door)
Bill Validator
Access Door
Power Supply
Main Power
Switch (located
on power supply)
Logic Unit
Housing
Printer
CAUTION: PCB’s may contain a lithium battery.
Danger of explosion if the battery is incorrectly
replaced. Replace only with the same, or
equivalent type recommended by the manufacturer.
WARNING: Power to the machine must be turned off prior
to cleaning the inside of the machine or removing any
mechanical or electrical assembly. Unplug the machine.
WARNING: Hazardous high voltage exists within the
cabinet even with machine power off and the power
cord unplugged! Use extreme caution when removing
electrical assemblies to avoid injury. Discharge body
static BEFORE touching PCBs to avoid damaging
electrostatic sensitive components. Only qualified
personnel should attempt servicing this machine.
CAUTION: Distributors, Operators, and Users are
not to modify the equipment for any other use. Konami
Gaming, Inc. cannot be held liable for damages or injuries
resulting from use or modification of this equipment.
Konami Gaming, Inc. cannot be held liable for damages or
injuries arising from improper or unsupervised installation,
modification, or use of equipment not manufactured or
approved by Konami Gaming, Inc. This equipment is
designed as a gaming device for amusement only, for sale
and use in jurisdictions permitting such devices.
FUNCTIONAL OVERVIEW
This chapter describes names and functions of the main parts� The following illustrations below to identify the major
components�
Tower Light
Hard Meters
LCD Edge
Light Panels
Bill Entry
Ticket Chute
Sub/Belly Door Logo
Button Panel
Sub Door Lock
Serial Plate
Main Door Lock
Elbow Light
Speakers
To Next Page
