Konami Concerto Crescent - P;N 310713 Assy, Topper, Tovis Lcd

SECTION 3 - PARTS, ASSEMBLIES & HARDWARE
1-3-26
3-26
© 2018 Konami Gaming Inc. P/N 810352
CONCERTO CRESCENT
(Original Instructions)
3
11
5
6
7
4
2
12
10
13
6
8
1
9
6
P/n 310713 assy, toPPer, tovis lcd
ITEM PART # DESCRIPTION
- 110892 HRNS, PDM2, LED, TOPPER2 (N/S)
1� 131010 ASSY, WLDMNT, TOPPER STAND
2� 192862 BRKT, SPRT, TOPPER
3� 310647 ASSY, DIFF, TOPPER
4� 410653 HSG, TOPPER
5� 410662 BEZEL, TOPPER
6� 450016 NUT, HEX KEP, 8-32 (12)
7� 450590
SCREW, TRUSS HD PHIL, 8-32 X �375, BLK
OXIDE (4)
ITEM PART # DESCRIPTION
8� 450596
SPACER, #8, �375OD X �281LG, NYLON, OFF-
WHITE (4)
9� 450597
PLUG, HOLE, �625 DIA X �016-�125 PNL THKNS,
BLK (4)
10� 450598 STUD, 8-32 X 1�25, W/ SLOT (4)
11� 530589 PCB, PODIUM2, LED, PDM2-TOPPER
12� 530649 LCD, TOVIS, 19�5”, WITH GLASS
13� 610097 TRIM, ELP, TOPPER
