Konami Concerto Crescent - P;N 331405 ASSY, CAB, MAIN (Fig� 2

SECTION 3 - PARTS, ASSEMBLIES & HARDWARE
1-3-11
3-11
© 2018 Konami Gaming Inc. P/N 810352
CONCERTO CRESCENT
(Original Instructions)
68
37
102
77
47
68
45
68
46
76
34
77
81
54
36
96
15
68
14
68
44
68 6
2
99
ITEM PART # DESCRIPTION
2� 131054 ASSY, WELD, MAIN CAB
6� 192696 BRKT, MTG, CPU HSG
14� 192772 PNL, CVR, SIDE, RT
15� 192773 PNL, CVR, FRNT
34� 310375 ASSY, BV, JCM IVISION, 1000 NOTE 72MM
36� 310610 ASSY, PS
37� 310612 ASSY, PNL, PWR CONT
44� 331270 ASSY, HSG, CPU
45� 331271 ASSY, HSG, BV
P/n 331405 assy, cab, Main (Fig. 2 oF 6)
ITEM PART # DESCRIPTION
46� 331272 ASSY, SW, BV DR
47� 331328 ASSY, SW, JCM CASHBOX
54� 410622 CHUTE, BV, JCM, UBA, IVIZION
68� 450016 NUT, HEX KEP, 8-32 (134)
76� 450122 SCREW, SEMS, PH PHIL, M3 X 6 (4)
77� 450127 SCREW, SEMS, PH PHIL, M4 X 6 (10)
81� 450167 SCREW, PH PHIL, M3 X 12 (2)
96� 450604 MAGNET, ADHESIVE BACKED
99� 470085 GASKET, BV CHUTE
102� 490078 CORD, AC
