Konica Minolta bizhub 361 Service Manual

3. PERIODIC CHECK
22
Field Service Ver.2.0 Mar. 2009
bizhub 501/421/361
3.4.2 Replacing the filter cover assy and the suction filter /A assy
A. Periodically replaced parts/cycle
• Filter cover assy : Every 250,000 prints *1
: Every 225,000 prints *2
• Suction filter /A assy : Every 250,000 prints *1
: Every 225,000 prints *2
*1 501/421
*2 361
B. Procedure
1. Remove the screw [1] and then remove the filter
cover assy [2].
2. Remove the suction filter /A assy [1].
50gaf2c015nb
[2]
[1]
50gaf2c016na
[1]
