3. PERIODIC CHECK
46
Field Service Ver.2.0 Mar. 2009
bizhub 501/421/361
3.11 Maintenance procedure of the paper feed section
3.11.1 Replacing the feed roller/pick-up roller (tray 1)
A. Periodically replaced parts/cycle
• Feed roller : Every 750,000 prints (Actual replacement cycle: Every 300,000 prints) *1
: Every 675,000 prints (Actual replacement cycle: Every 300,000 prints) *2
• Pick-up roller : Every 750,000 prints (Actual replacement cycle: Every 300,000 prints) *1
: Every 675,000 prints (Actual replacement cycle: Every 300,000 prints) *2
*1 501/421
*2 361
B. Procedure
1. Remove the front cover.
(See P.144)
2. Remove the tray 1.
(See P.161)
3. Remove the connector [1] and the 2 screws [2],
and then remove the paper feed unit /1 [3].
[2]
[1]
[3]
[2]
50gaf2c108na
