8 Parameter detail setup
© Copyright Reserved KONICS Co., Ltd. 85
8.3 DIGITAL INPUT SETUP(Digital input setting)
You can set executing function by digital input card, operation stauts, etc.
Move to DIGITAL INPUT SETUP with , keys, press key to enter DIGITAL
INPUT SETUP.
Parameter list
Parameter Set range Factory default
Select DI Card (Select digital input card) S7DI ↔ S8DI ↔ S9DI ↔ S10DI Automatically set
DI-□ Type (Select digital input □)
None ↔ Run ↔ Memo ↔ ListOut ↔ Speed ↔
Alarm Reset
None
DI-□ Reset No (Reset alarm number) None ↔ ALL ↔ S□AL-□ -
DI-□ Status (Operation status) Edge ↔ Level -
※Shaded parameters are affected by set value of other parameters. Please refer to specific
descriptions of each parameter.
