7 Operation
50 © Copyright Reserved KONICS Co., Ltd.
7.2 Special operation for record
KRN100 executes special operation for record with front keys ( , , , ).
(1) Start record (RUN)/Stop record (STOP)
Press front key at once, it starts recording and press this key once again, it stops
recording.
When digital input operation status is set as ‘Level’, you cannot start/stop record by front
key. In case of as ‘Edge’, start record (RUN)/stop record (STOP) function is available
with front k e y.
(2) Parameter’s set information print (List Print)
This function is to record the main parameter’s set information on recording paper. Press
key for over 3 sec. during recording or stop state, and it records the set information of
each menu.
For more information, please refer to ‘8.5.13 List Out Option (List record option)’.
Even if you print the parameter set information with max record speed (240mm/h), it takes a
lot of time. (It takes approx. 40 minutes for 12 channels.)
Be sure that for printing the list.
(3) Manual feed (FEED)
In record STOP state, press front key for over 3 sec, record state icon is changed to
icon and you can feed recording paper manually.
To tear recording paper, use this manual feed function at first.
(4) Digital memo (Digital Memo)
Press for over 3 sec, during recording status, digital input icon changes to
memo icon. It records current time (hh:mm:ss) and display value of each channel as
digital number on recording paper. It also displays ‘M’ which means the recording by memo
at front of current time.
