8 Parameter detail setup
92 © Copyright Reserved KONICS Co., Ltd.
8.4.1 Modbus Address (Communication address)
Designate communication address.
The designated communication address is able to apply to RS485, USB Device, also Ethernet
communication. However, duplicated communication address setting in same communication
line does not allow.
 Set range: 1 to 127
 Factory default: 1
8.4.2 RS485 Port (Use RS485 communication)
Set whether using RS485 communication.
If you set RS485 Port’s set value as ‘Enable’, Ethernet Port’s set value is changed ‘Disable’
automatically.
 Set range: Enable ↔ Disable
 Factory default: Enable
8.4.3 Baud Rate (Baud rate)
Designate baud rated.
 Set range: 2400 ↔ 4800 ↔ 9600 ↔ 19200 ↔ 38400 (unit: bps)
 Factory default: 9600
