CP308 Configuration
ID 1027-4487, Rev. 3.0 Page 4 - 21
P R E L I M I N A R Y
4.4.2 SMC Controller Status Register 1 (ICSTA1)
The SMC Controller Status Register 1 shows the overtemperature status of the GS45 GMCH
and the processor.
4.4.3 SMC Keyboard Controller-Style Interface
The host processor communicates with the SMC via a keyboard controller-style (KCS) inter-
face. This interface is for the System Management Software (SMS) used within an operating
system. The KCS interface is at the I/O location 0xCA2 and 0xCA3.
Table 4-21: SMC Controller Status Register 1 (ICSTA1)
REGISTER NAME SMC CONTROLLER STATUS REGISTER 1 (ICSTA1)
ADDRESS 0x29E
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 3 Res. Reserved 00000 R
2 ICHOT GMCH overtemperature detection (Aux2 trip point):
0 = GMCH is at its normal operating temperature
1 = GMCH temperature is above the AUX2 trip point
0R
1 Res. Reserved 0 R
0 IPHOT Processor overtemperature detection:
0 = Processor is at its normal operating temperature
1 = Processor temperature is above 105°C
0R
