A.2 Technical Specifications
Table A-1: CP308-HDD Module Specifications
CP308-HDD SPECIFICATIONS
Front Panel
Interfaces
Keyboard and
Mouse
PS/2 type, 6-pin, shielded mini-DIN connector for the keyboard and mouse (via Y-
cable), J4
Serial Port One 16C550-compatible serial port (COM1), RS-232; 9-pin D-Sub connector; J5
USB Two USB 2.0 connectors, J2 and J3
DVI-D One DVI-D connector with digital signals only, J1
Onboard
Interfaces
USB NAND Flash One USB 2.0 connector, J6, for connecting a USB 2.0 NAND Flash module
SATA SATA connector, J7, for connecting a SATA 2.5” HDD/SSD
CompactFlash One CompactFlash card socket, J9, True IDE with DMA (IDE master only)
Board-to-Board Two board-to-board connectors for connecting the module to the CP308:
• One high-speed graphics extension connector, J10
• One high-speed I/O extension connector, J8
Indicators/
Switches
HDD LED One LED (green) monitors SATA hard disk activity
Front Panel Switch Reset button, guarded
General
Power Consumption Power consumption without hard disk and without peripheral devices connected:
100 mA at 3.3 V
Temperature Range Operational: 0°C to +60°C Standard
Storage: -55°C to +85°C Without hard disk and without battery
-40°C to +65°C With hard disk
Climatic Humidity 93% RH at 40°C, non-condensing (acc. to IEC 60068-2-78)
Dimensions Dimensions: 100 mm x 158 mm
Board Weight 590 grams (8 HP CP308 with CP308-HDD, copper heat sink, front panel, two 2 GB
SODIMM memory modules and battery, but without USB NAND Flash module, Com-
pactFlash card and 2.5” HDD/SSD)
460 grams (8 HP CP308 with CP308-HDD, aluminum heat sink, front panel, two 2 GB
SODIMM memory modules and battery, but without USB NAND Flash module, Com-
pactFlash card and 2.5” HDD/SSD)
Battery 3.0V lithium battery for RTC with battery socket. Recommended type: CR2025
Temperature ranges:
Operational: -20°C to +70°C typical (refer to the battery manufacturer’s specifica-
tions for exact range)
Storage: -55°C to +70°C typical (no discharge)
Note ...
When a battery is installed, refer to the operational specifications
of the battery as this determines the storage temperature of the
CP308-HDD module (See "Battery" below).
