C. CP-RIO3-04 Rear I/O Module
C.1 Overview
The CP308 provides optional rear I/O connectivity for peripherals, a feature which may be
particularly useful in specialized CompactPCI systems. Some standard PC interfaces are
implemented and assigned to the front panel and to the rear I/O connector J2 on the CP308.
When the CP-RIO3-04 rear I/O module is used, the signals of some of the main board/front
panel connectors are routed to the module interface.
To support the rear I/O feature, a 3U CompactPCI backplane with rear I/O support is required.
The CP308 with rear I/O is compatible with all standard CompactPCI passive backplanes with
rear I/O support on the system slot.
The CP-RIO3-04 rear I/O module provides the following interfaces.
• CompactPCI rear I/O
• Two USB 2.0 ports
• Two Gigabit Ethernet ports without LED signals
• Two COM ports
• VGA analog port
•Two SATA ports
• One fan monitor input
• One fan control output (PWM)
• Power supply management
