3.5 Installation of CP308 Peripheral Devices
The CP308 is designed to accommodate various peripheral devices, such as USB devices, Se-
rial ATA devices, a CompactFlash card, an SD/SDHC card, a PCI Express Mini Card, etc. The
following figures show the placement of modules and peripheral devices on the CP308.
Figure 3-1: Connecting a Peripheral Device to the 4HP CP308
Figure 3-2: Connecting a Peripheral Device to the 8HP CP308 with CP308-HDD
USB 2.0 NAND
Flash Module
SATA con. for external
SATA devices
USB 2.0 NAND
Flash Module
2.5” Serial ATA HDD/SSD
CP308-HDD
Module
