4.3.7 Board Interrupt Configuration Register (BICFG)
The Board Interrupt Configuration Register holds a series of bits defining the interrupt routing
for the Watchdog. If the Watchdog timer fails, it can generate an IRQ5 interrupt.
The enumeration signal is generated by a hot swap compatible board after insertion and prior
to removal. The system uses this interrupt signal to force software to configure the new board.
The derate signal indicates that the power supply is beginning to derate its power output.
Table 4-10: Board Interrupt Configuration Register (BICFG)
REGISTER NAME BOARD INTERRUPT CONFIGURATION REGISTER (BICFG)
ADDRESS 0x286
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 6 CFICF CPCI fail signal interrupt configuration (FAL signal):
00 = Disabled
01 = IRQ5
10 = Reserved
11 = Reserved
00 R/W
5 CEICF CPCI enumeration signal to IRQ5 routing (ENUM signal):
0 = Disabled
1 = Enabled
0R/W
4 CDICF CPCI derate signal to IRQ5 routing (DEG signal):
0 = Disabled
1 = Enabled
0R/W
3 - 2 KICF KCS interrupt configuration:
00 = Disabled
01 = IRQ11
10 = IRQ10
11 = Reserved
00 R/W
1 - 0 WICF Watchdog interrupt configuration:
00 = Disabled
01 = IRQ5
10 = Reserved
11 = Reserved
00 R/W
