CP308 Configuration
ID 1027-4487, Rev. 3.0 Page 4 - 9
P R E L I M I N A R Y
4.3.5 Device Protection Register (DPROT)
The Device Protection Register holds the write protect signals for Flash devices.
Table 4-8: Device Protection Register (DPROT)
REGISTER NAME DEVICE PROTECTION REGISTER (DPROT)
ADDRESS 0x284
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 2 Res. Reserved 000000 R
1 EEWP EEPROM write protection:
0 = EEPROM not write protected
1 = EEPROM write protected
Writing a ’1’ to this bit sets the bit. If this bit is set, it cannot be
cleared.
0R/W
0 BFWP Boot Flash write protection:
0 = Boot Flash not write protected
1 = Boot Flash write protected
Writing a ’1’ to this bit sets the bit. If this bit is set, it cannot be
cleared.
0R/W
