Introduction CP308
Page 1 - 14 ID 1027-4487, Rev. 3.0
P R E L I M I N A R Y
1.5 Kontron Software Support
Kontron is one of the few CompactPCI and VME vendors providing inhouse support for most
of the industry-proven real-time operating systems that are currently available. Due to its close
relationship with the software manufacturers, Kontron is able to produce and support BSPs and
drivers for the latest operating system revisions thereby taking advantage of the changes in
technology.
General
Mechanical 3U, 4HP, CompactPCI-compliant form factor
Power Consumption See Chapter 5 for details.
Temperature Range Operational: 0°C to +60°C Standard (depending on processor version
and airflow in the system)
Storage: -55°C to +85°C Without hard disk and without battery
Battery 3.0V lithium battery for RTC with battery socket.
Recommended type: CR2025
Temperature ranges:
Operational (load): -20°C to +70°C typical (refer to the battery manufac-
turer’s specifications for exact range)
Storage (no load): -55°C to +70°C typical (no discharge)
Climatic Humidity 93% RH at 40°C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 100 mm x 160 mm
Board Weight 460 grams (4 HP CP308 with copper heat sink, front panel, two 2 GB SODIMM
memory modules, and battery but without USB NAND Flash module)
330 grams (4 HP CP308 with aluminum heat sink, front panel, two 2 GB
SODIMM memory modules, and battery but without USB NAND Flash module)
Note ...
For a description of the additional 8HP version interfaces, refer to Appendix A,
CP308-HDD Module and Appendix B, CP308-MEDIA Module.
Table 1-1: 4HP CP308 Main Specifications (Continued)
CP308 SPECIFICATIONS
Note ...
When a battery is installed, refer to the operational specifications
of the battery as this determines the storage temperature of the
CP308 (See "Battery" below).
Note ...
When additional components are installed, refer to their opera-
tional specifications as this will influence the operational and stor-
age temperature of the CP308.
