1.4 Technical Specification
Table 1-1: 4HP CP308 Main Specifications
CP308 SPECIFICATIONS
Processor and Memory
CPU The CP308 supports the following 45-nm microprocessors:
• Intel® Core™2 Duo processor SU9300 (ULV), 1.2 GHz, 800 MHz FSB,
3 MB L2 cache
• Intel® Core™2 Duo processor SL9400 (LV), 1.86 GHz, 1066 MHz FSB,
6 MB L2 cache
• Intel® Core™2 Duo processor SP9300 (SV), 2.26 GHz, 1066 MHz FSB,
6 MB L2 cache
All microprocessors are provided in a 956-ball Micro-FCBGA package.
Memory Main Memory:
• Up to 8 GB Dual-Channel DDR3 SDRAM memory on two SODIMM sockets
• 800/1066 MHz memory bus
• Error Checking and Correction (ECC) not provided
Cache structure:
• 64 kB L1 on-die full-speed processor cache
• 32 kB for instruction cache
• 32 kB for data cache
• Up to 6 MB L2 on-die full speed processor cache
FLASH Memory:
• Two SPI Flash chips for redundant uEFI BIOS
• USB 2.0 NAND Flash memory optionally available
Serial EEPROM:
• 24LC64 (64 kbit)
