Kontron CP308 - CPU, Memory and Chipset; CPU

CP308 Functional Description
ID 1027-4487, Rev. 3.0 Page 2 - 3
P R E L I M I N A R Y
2. Functional Description
2.1 CPU, Memory and Chipset
2.1.1 CPU
The CP308 supports the Intel® Core™2 Duo processors with 1.2 GHz (SU9300), 1.86 GHz
(SL9400) and 2.26 GHz (SP9300) built on 45-nm process technology delivering optimized
power-efficient computing and outstanding dual-core performance with low power
consumption.
The following list sets out some of the key features of these processors:
• Two mobile execution cores in one single processor
• Support of Intel® 64 Architecture
• Up to 1066 MHz, Source-Synchronous Front Side Bus (FSB)
• 64 kB L1 cache (32 kB instruction cache and 32 kB write-back data cache)
• Up to 6 MB L2 cache
• SSE4 instruction set
• Intel® Dynamic Acceleration Technology (Turbo Mode)
• Enhanced Intel® Virtualization Technology (VT-d1)
• Advanced Power Management features including Enhanced Intel® SpeedStep® tech-
nology
• Enhanced Multi-Threaded Thermal Management (EMTTM)
The following tables indicate the Intel® Core™2 Duo processors supported on the CP308, their
maximum power dissipation and their frequency in the various SpeedStep® modes.
1)
ULV: Ultra Low Voltage
2)
LV: Low Voltage
3)
SV: Standard Voltage
Table 2-1: Processors Supported on the CP308
SPEED
Core™2 Duo
1.2 GHz (ULV
1)
)
3 MB L2 Cache
Core™2 Duo
1.86 GHz (LV
2)
)
6 MB L2 Cache
Core™2 Duo
2.26 GHz (SV
3)
)
6 MB L2 Cache
PACKAGE
956-ball Micro-FCBGA 956-ball Micro-FCBGA 956-ball Micro-FCBGA
L2 CACHE
3 MB 6 MB 6 MB
FSB
800 MHz 1066 MHz 1066 MHz
