CP308 Introduction
ID 1027-4487, Rev. 3.0 Page 1 - 5
P R E L I M I N A R Y
1.2 System Expansion Capabilities
1.2.1 CP308-HDD Module
The CP308-HDD module for the 8HP CP308 version provides legacy PC I/O ports. It includes
one digital DVI port, two USB 2.0 ports, one COM port, a PS/2 keyboard and mouse port, one
USB 2.0 NAND Flash connector, and one CompactFlash card socket. A SATA hard disk
interface is also available for installing a Serial ATA 2.5” HDD or SSD.
For further information concerning the CP308-HDD module, refer to Appendix A.
1.2.2 CP308-MEDIA Module
The CP308-MEDIA module for the 8HP CP308 version provides multimedia I/O ports. It
includes two DisplayPorts, one S/P-DIF-Out port, one triple audio jack (Mic-In, Line-In and
Line-Out), one CD-In port, one internal line-out mono port, one COM port, one PCI Express
Mini Card connector, one SD/SDHC card socket, and one CompactFlash card socket. A SATA
hard disk interface is also available for installing a Serial ATA 2.5” HDD or SSD.
For further information concerning the CP308-MEDIA module, refer to Appendix B.
1.2.3 CP-RIO3-04 Rear I/O Module
The CP-RIO3-04 rear I/O module has been designed for use with the CP308 board from
Kontron and provides comprehensive rear I/O functionality.
For further information concerning the CP-RIO3-04 rear I/O module, refer to Appendix C.
1.2.4 USB 2.0 NAND Flash Module
The CP308 provides support for one optional USB 2.0 NAND Flash module. For further infor-
mation, refer to chapter 2.2.6, "USB 2.0 NAND Flash Module".
1.3 Board Diagrams
The following diagrams provide additional information concerning board functionality and
component layout.
