Power Considerations CP308
Page 5 - 8 ID 1027-4487, Rev. 3.0
P R E L I M I N A R Y
5.3 Power Consumption of CP308 Accessories
The following table indicates the power consumption of the CP308 accessories.
5.4 Start-Up Currents of the CP308
The following table indicates the basic start-up currents of the CP308 during the first 2-3 sec-
onds after the power supply has been switched on. The power consumption of the CP308 dur-
ing operation is indicated in tables 5-4 to 5-8.
For further information on the start-up current, please contact Kontron.
5.5 +5 V STDBY Currents During Main Power-Off
For the Wake-on-LAN (WOL) feature when the main DC power supplies are off, the CP308 pro-
vides a 5 V stand-by supply option over the CompactPCI Rear I/O connector J2, pin A15. In
stand-by mode, the CP308 has the following power consumption:
In stand-by mode, only the WOL-relevant devices on the CP308 are powered. Once the CP308
is supplied with main power, the stand-by path is automatically switched off.
Table 5-9: Power Consumption of CP308 Accessories
MODULE POWER 5 V
POWER 3.3 V
AVERAGE
Keyboard approx. 0.3 W —
Mouse approx. 0.3 W —
DDR3 SDRAM update from 2 GB to 4 GB — approx. 1 W
DDR3 SDRAM update from 2 GB to 8 GB — 1 W - 2 W
USB 2.0 NAND Flash module 0.3 W - 0.5 W —
Gigabit Ethernet (per interface) approx. 0.7 W —
Table 5-10: Start-Up Currents of the CP308
POWER
CORE™2 Duo
1.2 GHz (ULV)
CORE™2 DUO
1.86 GHz (LV)
CORE™2 DUO
2.26 GHz (SV)
5 V peak 5 A 5 A 5 A
average 1.3 A 1.3 A 1.3 A
3.3 V peak 4.3 A 4.3 A 4.3 A
average 1.6 A 1.6 A 1.6 A
Table 5-11: +5 V STDBY Start-Up Currents During Main Power-Off
POWER
NO ETHERNET
CONNECTED
10 Mbit WOL ENVIRONMENT 100 Mbit WOL ENVIRONMENT
+5 V STDBY 70 mA One Eth. connector connected: 105 mA One Eth. connector connected: 110 mA
Two Eth. connectors connected: 140 mA Two Eth. connectors connected: 150 mA
