CP308 Functional Description
ID 1027-4487, Rev. 3.0 Page 2 - 19
P R E L I M I N A R Y
2.3.9.2 CompactPCI Connectors J1 and J2 Pinouts
The CP308 is provided with two 2 mm x 2 mm pitch female CompactPCI bus connectors, J1
and J2.
Table 2-14: CompactPCI Bus Connector J1 System Controller Slot Pinout
PIN ROW Z ROW A ROW B ROW C ROW D ROW E ROW F
25 NC 5V REQ64# ENUM# 3.3V 5V GND
24 NC AD[1] 5V V(I/O) AD[0] ACK64# GND
23 NC 3.3V AD[4] AD[3] 5V AD[2] GND
22 NC AD[7] GND 3.3V AD[6] AD[5] GND
21 NC 3.3V AD[9] AD[8] M66EN C/BE[0]# GND
20 NC AD[12] GND V(I/O) AD[11] AD[10] GND
19 NC 3.3V AD[15] AD[14] GND AD[13] GND
18 NC SERR# GND 3.3V PAR C/BE[1]# GND
17 NC 3.3V IPMB SCL IPMB SDA GND PERR# GND
16 NC DEVSEL# PCIXCAP V(I/O) STOP# LOCK# GND
15 NC 3.3V FRAME# IRDY# BDSEL# TRDY# GND
12-14 Key Area
11 NC AD[18] AD[17] AD[16] GND C/BE[2]# GND
10 NC AD[21] GND 3.3V AD[20] AD[19] GND
9 NC C/BE[3]# NC AD[23] GND AD[22] GND
8 NC AD[26] GND V(I/O) AD[25] AD[24] GND
7 NC AD[30] AD[29] AD[28] GND AD[27] GND
6 NC REQ0# CPCI_PRESENT# 3.3V CLK0 AD[31] GND
5NCNC NC RST#GNDGNT0#GND
4 NC IPMB PWR HEALTHY# V(I/O) RSV RSV GND
3 NC INTA# INTB# INTC# 5V INTD# GND
2NCTCK5V TMSNC TDI GND
1 NC 5V NC TRST# NC 5V GND
