Functional Description CP308
Page 2 - 4 ID 1027-4487, Rev. 3.0
P R E L I M I N A R Y
4)
HFM High Frequency Mode
5)
LFM Low Frequency Mode
Table 2-2: Maximum Power Dissipation of the Processors (CPU only)
FREQUENCY MODE
Core™2 Duo
1.2 GHz (ULV)
3 MB L2 Cache
Core™2 Duo
1.86 GHz (LV)
6 MB L2 Cache
Core™2 Duo
2.26 GHz (SV)
6 MB L2 Cache
Maximum Power
HFM
4)
10 W
(1.2 GHz)
17 W
(1.86 GHz)
25 W
(2.26 GHz)
Maximum Power
LFM
5)
10 W
(1.2 GHz)
16.7 W
(1.6 GHz)
20 W
(1.6 GHz)
Maximum Power
Super LFM
8 W
(600 MHz)
10 W
(800 MHz)
11 W
(800 MHz)
Table 2-3: CPU Frequency in the Various SpeedStep® Modes
FREQUENCY
Core™2 Duo
1.2 GHz (ULV)
3 MB L2 Cache
Core™2 Duo
1.86 GHz (LV)
6 MB L2 Cache
Core™2 Duo
2.26 GHz (SV)
6 MB L2 Cache
2.26 GHz -- -- x
1.86 GHz -- x --
1.6 GHz -- x x
1.33 GHz -- -- --
1.2 GHz x -- --
1.0 GHz -- -- --
800 MHz -- x x
600 MHz x -- --
