CP308 Functional Description
ID 1027-4487, Rev. 3.0 Page 2 - 21
P R E L I M I N A R Y
Table 2-16: 64-bit CompactPCI Bus Connector J2 Pinout (CP308 Front I/O Vers.)
PIN ROW Z ROW A ROW B ROW C ROW D ROW E ROW F
22 NC NC NC NC NC NC GND
21 NC CLK6 GND RSV RSV RSV GND
20 NC CLK5 GND RSV RSV RSV GND
19 NC GND GND RSV RSV RSV GND
18 NC RSV RSV RSV RSV RSV GND
17 NC RSV RSV PRST# REQ6# GNT6# GND
16 NC RSV RSV DEG# RSV RSV GND
15 NC RSV RSV FAL# REQ5# GNT5# GND
14 NC AD[35] AD[34] AD[33] RSV AD[32] GND
13 NC AD[38] RSV RSV AD[37] AD[36] GND
12 NC AD[42] AD[41] AD[40] RSV AD[39] GND
11 NC AD[45] RSV RSV AD[44] AD[43] GND
10 NC AD[49] AD[48] AD[47] RSV AD[46] GND
9 NC AD[52] GND RSV AD[51] AD[50] GND
8 NC AD[56] AD[55] AD[54] GND AD[53] GND
7 NC AD[59] RSV RSV AD[58] AD[57] GND
6 NC AD[63] AD[62] AD[61] GND AD[60] GND
5 NC C/BE[5]# GND RSV C/BE[4]# PAR64 GND
4 NC V(I/O) RSV C/BE[7]# RSV C/BE[6]# GND
3 NC CLK4 GND GNT3# REQ4# GNT4# GND
2 NC CLK2 CLK3 SYSEN# GNT2# REQ3# GND
1 NC CLK1 GND REQ1# GNT1# REQ2# GND
Note ...
The 64-bit CompactPCI signals are not used on the board, but all 64-bit control and
address signals are terminated to V(I/O).
