3 Operation
3.42 Washer system (option)
Front wiper operation
Notice!
This equipment is only available with a cabin.
Wiper switch 65 is located on the switch console on the right.
Front/rear washer pump operation
Notice!
This equipment is only available with a cabin.
Rear washer system operation
Notice!
This equipment is only available with a cabin.
Switch A for the rear washer system is located on the wiper motor of the rear window.
Fig. 83 : Front wiper switch
65
B
A
Front window wiper
ON
☞Press switch 65 to position B ➥Front wiper is on
OFF
☞Press switch 65 to position A ➥Front wiper returns to base
position
Fig. 84 : Washer pump switch
65
B
A
Washer pump for front and rear window
ON
☞Fully press and hold switch 65 in position B
OFF
☞Release switch 65
Fig. 85 : Rear wiper switch
A
18
Rear wiper
ON
☞Press switch A on wiper motor 18
to position 1
➥Rear wiper is on
OFF
☞Press switch A on wiper motor 18
to position 0
➥Rear wiper returns to base position
