BA 348-01 * 2.0 * 34801b340.fm 3-95
Operation 3
Backfilling round gravel and precise unloading
• Precise dosing and placement of pourable material
• Bucket teeth move back from the wall as the bucket opens
Unloading from the bottom of the bucket for increased tilt-out heights
• Unloading from the bottom of the bucket for increased tilt-out heights
• Tilt-out height can be increased by at least 55 cm (depending on bucket size), as
compared to tilting out normally with a standard bucket.
Smaller tilt reach is compensated by pushing the material with the open
multipurpose bucket as shown.
Ansicht_012.iso
Ansicht_011.iso
Fig. 134 : Backfilling and unloading material with
a multipurpose bucket
Ansicht_010.iso
Ansicht_013.iso
Fig. 135 : Unloading from the bottom of a multipurpose
bucket
