BA 348-01 * 2.0 * 34801b610.fm 6-1
Technical data 6
6 Technical data
6.1 Models and trade names (overview)
6.2 Frame
Sturdy steel sheet chassis, rubber-mounted engine
6.3 Engine
Wheel loader model Trade name
348-01 350 / 5035
Wheel loader model 348-01
Product Yanmar diesel engine
Type 3TNV 88 3TNV 84T (option)
Design Water-cooled 4 stroke diesel engine
Number of cylinders 3
Displacement 1642 cm³ 1496 cm³
Nominal bore and stroke 88 x 90 mm 84 x 90 mm
Output (kW) as per ISO
23 kW
at 2600 rpm
27 kW
at 2600 rpm
Max. torque
99 – 107 Nm
at 1560 rpm
114 – 124 Nm
at 1560 rpm
Max. engine speed without load 2810 rpm
Idling speed 1100 rpm 800 rpm
Specific fuel consumption 271 g/kWh 261 g/kWh
Fuel injection system Direct injection
Firing order 1–3–2
Starting aid Glow plug (preheating time 10 – 15 seconds)
Max. inclined position
(engine no longer supplied with oil):
25° in all directions
Observe the tilting limit (20° laterally) of the machine!
Exhaust values according to 2004/26 EC
