3-84 BA 348-01 * 2.0 * 34801b340.fm
3 Operation
3.51 Installing a multipurpose bucket and hydraulic attachments
Fields of application for multipurpose bucket
• The multipurpose bucket is mainly used for earthwork, for grading, picking up,
loosening, filling transporting and loading loose or solid materials.
The multipurpose bucket is not certified for applications with lifting gear!
Hitching hooks, eyelets or other lifting gear onto the multipurpose bucket is
prohibited as well!
• Machine travel on public roads with a full bucket is prohibited according to StVZO
(German road traffic regulations).
• Use of attachments on public roads
–seePutting the machine into operation on page 3-51!
Installing a multipurpose bucket
In order to avoid risk of accidents and damage on the quickhitch,
check mounting bore L of the attachment regularly for damage
–seeChecking the mounting bore of the attachment on page 3-73!
In order to avoid risk of accidents, ensure that the attachment is safely locked
onto the quickhitch by means of the lock ram before starting work!
☞You must be able to see the lock pins on either side of the mounting holes
on the attachment!
☞–seeField of application and use of bucket on page 3-73
The multipurpose bucket is picked up and installed on the quickhitch in the
same way as the standard bucket –seeField of application and use of bucket
on page 3-73.
Fig. 118 : Checking the lock pins
