Kramer MV-6 User Manual

20
MV-6 - Operating the MV-6 Locally
6.9.1 Windows Sub-Menu
The parameters in the Windows Sub-Menu set the window inputs and
characteristics.
Parameter
Description
Values
Select window
Selects the window to adjust
A, B, C, D, E, F
Default—F
Visibility
Makes the selected window visible or non-
visible
Visible,
Non-Visible
Default—Visible
Select layer
Selects a source to display in the selected
window
TOP, 2, 3, 4, 5, 6
Default—TOP
Input
Selects an input
1, 2, 3, 4, 5, 6
Default—1
Size
Hor
size(%)
Sets the horizontal size for the selected
window
1 to 100
Default— 66
Ver
size(%)
Sets the vertical size for the selected
window
1 to 100
Default— 66
Position
X
origin(%)
Sets the X origin for the selected window
0 to 99
Default— 0
Y
origin(%)
Sets the Y origin for the selected window
0 to 99
Default— 0
Freeze
Freezes or releases the video
ON, OFF
Default—OFF
6.9.2 Output Sub-Menu
The parameters in the Output Sub-Menu set the output and LCD preview
screen characteristics.
Note: NTSC or PAL is automatically selected depending on the selected output
resolution refresh rate.
Parameter
Description
Values
RESOLUTION
Sets the output
resolution
720p59.94, 720p60, 720p50,
1080p59.94, 1080p60, 1080p50
Default— 720p59.94
GENLOCK MODE
Turns on and off and
sets the source of the
unlock signal
NO GENLOCK, INPUT 1, INPUT 2,
INPUT 3, INPUT 4, INPUT 5,
INPUT 6
Default—NO GENLOCK
BACKGROUND >
Sets the background
color using R, G and B
values
000 to 255
Default—R=1, G=101, B=53
WIN BORDER
Turns the window border
on or off
ON, OFF
Default—ON
WIN TEXT
Turns the window text
labels on and off
ON, OFF
Default—ON
