Terminal – Menus

150

Pos: 45.21 /BA/Inf o-Center/ALLE Terminals i n einem - ISOBUS, Delta, BE TA II (ab BJ 15/16)/ALLE Termina ls/Übergreif end über alle Maschinen/ Menü auswählen_Text2-über das Scrollrad_ISOB US Terminal @ 389\mod_1445504 944161_78.doc x @ 2788237 @ @ 1

Via scroll wheel

• Navigate to a menu by using the scroll wheel (4).

The selected menu is grey shaded and bordered in green.

• To open the menu, press icon

or key F3.

• To leave a menu, press icon

or key F5.

The menu closes.

Pos: 45.22.1 /Überschr iften/Überschr iften 2/U-Z/W/W ert ändern_Terminal @ 381\mod_1 444052936020_78.d ocx @ 2750606 @ 2 @ 1

14.5 Changing the value

Pos: 45.22.2 /BA/I nfo-Center/ALLE Termina ls in einem - ISOBUS, Delta, BETA II (ab BJ 15/16)/ ALLE Terminals/Übergrei fend über alle Maschi nenWerte eingeben_Einlei tung_ALLE Terminals @ 351\ mod_1437116259297_ 78.docx @ 2632676 @ @ 1

To configure the machine, values must be entered or changed in the menus.

Pos: 45.22.3 /Überschr iften/Zwischenü berschriften/A- E/Bei Ausführung BETA II- Terminal @ 384\mod_14446 43356780_78.doc x @ 2758467 @ @ 1

With version BETA II terminal

Pos: 45.22.4 /BA/I nfo-Center/ALLE Termina ls in einem - ISOBUS, Delta, BETA II (ab BJ 15/16)/ ALLE Terminals/Übergrei fend über alle Maschi nenWerte eingeben_Zusam menfassung_BETA II Termin al @ 351\mod_1437116365 459_78.docx @ 2632738 @ @ 1

There are two possibilities to enter the values:

– Enter by using the scroll wheel

– Enter by selecting the keys

and

Pos: 45.22.5 /Überschr iften/Zwischenü berschriften/A- E/Bei Ausführung ISOB US-Terminal @ 384\mod_1444643 434486_78.doc x @ 2758498 @ @ 1

For version ISOBUS terminal

Pos: 45.22.6 /BA/I nfo-Center/ALLE Termina ls in einem - ISOBUS, Delta, BETA II (ab BJ 15/16)/ ALLE Terminals/Übergrei fend über alle Maschi nen/Werte eingeben_Zusa mmenfassung_ISOB US Terminal @ 392\mod_144603 0656329_78.docx @ 28058 35 @ @ 1

Values which can be changed are marked in blue on the display. There are three possibilities to

enter values:

– via scroll wheel (if available)

– by selecting the keys

and

– by tipping the blue value on the touch sensitive display

If a numeric value is tipped in the menu, a further input window opens. Three different forms of

presentation are available to enter the value. For further information on entry of values, refer to

the provided operating instructions of the terminal.

Pos: 45.22.7 /Überschr iften/Zwischenü berschriften/A- E/Beispiele @ 351\mod_1437 118881188_78.doc x @ 2632954 @ @ 1

Examples

Pos: 45.22.8 /BA/I nfo-Center/ALLE Termina ls in einem - ISOBUS, Delta, BETA II (ab BJ 15/16)/ ALLE Terminals/Übergrei fend über alle Maschi nenWerte eingeben_1Bsp- Über das Scrollrad_ALLE Terminals @ 351\mod_14371 18213449_78.doc x @ 2632769 @ @ 1

Via scroll wheel

• Choose the value to be changed using the scroll wheel.

The selection box is highlighted in colour.

• Press the scroll wheel.

An input window opens.

• Turn the scroll wheel to increase or reduce the value.

• Press the scroll wheel to save the value.

The setting is adopted, the input window closes.

Pos: 45.22.9 /BA/I nfo-Center/ALLE Termina ls in einem - ISOBUS, Delta, BETA II (ab BJ 15/16)/ ALLE Terminals/Übergrei fend über alle Maschi nenWerte eingeben_2Bsp- Über Plus Minus_ALLE Ter minals @ 351\mod_14371182 74071_78.docx @ 263280 0 @ @ 1

Via plus/minus keys

• Select to increase the value.

• Select

to reduce the value.

• Select

to save the value.

The setting is saved, the input window closes.

Pos: 45.22.10 /BA/I nfo-Center/ALLE Termina ls in einem - ISOBUS, Delta, BETA II (ab BJ 15/16)/ ALLE Terminals/Übergrei fend über alle Maschi nenWerte eingeben_3Bs p-Über den Wert_nur I SOBUS Terminal @ 351\mod_14371187 86488_78.docx @ 2632923 @ @ 1

Via value (for version with ISOBUS terminal)

• Tip the value to be changed (highlighted in blue) on the touch sensitive display.

An input window opens.

• Increase or reduce the value.

• Select

to save the value.

The setting is saved, the input window closes.
