Krone Profi Liner - Page 149

LOADING AND SECURING
Operating instructions • Semitrailer • 505369471-04 • 02/2019
149
1
Fig.8-33: Folding up the safety cover
1 Safety cover
► Fold up the safety cover.
► Repeat the work steps on the front
corner post.
Fig.8-34: Opening the quick-release ten-
sioner
► Open the front and rear quick-release
tensioners.
► Stow the quick-release tensioners in
the curtain cut-out.
► Open the side curtain (see "6.2.1 Side
curtain", pg.74).
ü The Multi Tyre system is open.
Closing the Multi Tyre system
► Close the side curtain (see "6.2.1 Side
curtain", pg.74).
Fig.8-35: Closing the quick-release tension-
ers
► Close the front and rear quick-release
tensioners.
1
Fig.8-36: Folding down the safety cover
1 Safety cover
► Fold down the safety cover over the
quick-release tensioner.
1
Fig.8-37: Closing the pump valve
1 Pump valve
