V - 15
Basic Settings and Operation
• Shut the cleaning flaps (1).
• Rotate the stepped roller in the direction of the arrow
until the twine holders (3) move from the outside to the
centre starting position.
The twine holders (3) must move to the centre when the
stepped roller is rotated. Otherwise continue to rotate the
stepped roller in the direction of the arrow until the
starting position (see illustration) has been reached.
The spacing between individual twine wraps on the bale
can be changed by inserting the baler twine into different
grooves of the stepped roller.
length of choose following wrap
baling stepped roller diameter spacing
material
short large (1) narrow
medium medium medium
long small (2) wide
• Thread the twine from the twine brake around the
stepped roller (1) to the distributor eyelets (2).
• Then thread it through the twine guides (3) and (4) to
the rubber-coated roller (5).
The twine should extend at least 40 cm
from the rubber-coated roller.
RP-A-020
1
2
2
1
3
CP400003
