Startup
The Rear Panel
2-3
NOTE: You can perform a quick check of the K2vxR and your audio system without a MIDI
controller connected to the K2vxR. Hold down the CANCEL button on the alphanumeric pad
and press any other alphanumeric button, and you should hear notes. See "The Panel Play
Feature" in Chapter 3 for more information about this feature.
Connecting SCSI
You may not have a hard disk or other SCSI device to connect to your K2vx right away, but if
you do, you can connect it to either of the SCSI ports. Please read the following information
carefully; itÕs very important.
IMPORTANT NOTE: If you plan to connect more than one SCSI device to the K2vx (including
an Apple Macintosh
Ã’
), you
must
terminate your SCSI chain properly. Turn to Chapter 13 and
read the section called ÒSCSI Termination.Ó You can lose data, and possibly damage your K2vx
and SCSI devices if theyÕre not terminated properly.
Switching On the Power
The power switch is located at the lower left of the front panel. When you power up, the
display will brießy say ÒWelcome to the K2vx!Ó The Program Mode display will then appear. It
looks like the diagram below (the programs shown in the diagram donÕt necessarily exist):
ProgramMode||||Xpose:0ST|||<>Channel:1||
!!!!!!!!!!!!!!!!!!@
|198|Analog|Jam||||||
KeyMap|Info|||||||
#
|
199|Default|Program|
|
Grand|Piano|||||
|
#
|
||1|Righteous|Piano|
||||||||||||||||||
#
|||2|Mondo|Bass||||||
||||||||||||||||||
#
|||3|Killer|Drums||||
%%%%%%^%%%%%%^%%%%$
|
|
|4|Wee
p
ing|Gu
i
tar||
Octav-
|
Octav+
|
Panic|
|
View||
|
Chan-|
|
Chan+
Set the volume at a comfortable level. YouÕll get the best signal-to-noise ratio if you keep the
K2vx at full volume (turn the volume knob fully clockwise), and adjust the level from your
mixing board. You may also want to adjust the display contrast. This is done with the Contrast
parameter in Master mode. See Chapter 11. As you trigger notes from your MIDI controller,
youÕll see the MIDI LED ßash. If it doesnÕt ßash, check your MIDI cables and connections.
