KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 110 -
Type 10: Connector at ZR-613: SSI- actuated encoder Type ECN10TL-03 SSI-Protocol
Termina
Function
ECN10TL-03
Pin 1: PE
Earth
Pin 2: 91
Clock +
Pin 3: 92
Clock -
Pin 4: 93
Data +
Pin 5: 94
Data -
Pin 6: 500
0 V DC
Pin 7: 050
+5V DC
Pin 8: 200
+24V DC
Type 11: Connector at ZR-613: SSI- actuated encoder Type ECN10TL-05 SSI-Protocol
Termina
Function
ECN10TL-05
Pin 1: PE
Earth
Pin 2: 91
Clock +
Pin 3: 92
Clock -
Pin 4: 93
Data +
Pin 5: 94
Data -
Pin 6: 500
0 V DC
Pin 7: 050
+5V DC
Pin 8: 200
+24V DC
Type 12: Connector at ZR-613: SSI- actuated encoder Type ECN10TL10 SSI-Protocol
Termina
Function
ECN10TL-10
Pin 1: PE
Earth
Pin 2: 91
Clock +
Pin 3: 92
Clock -
Pin 4: 93
Data +
Pin 5: 94
Data -
Pin 6: 500
0 V DC
Pin 7: 050
+5V DC
Pin 8: 200
+24V DC
Type 13: Connector at FKR-613-CAN: CAN-Absolutvalueencoder CanOpen-protocol
only visible if absolute copying (Menu-A3) as well as CAN-Bus + CAN-encoder activated A402 / A403)
encoder system : Connection on FKR-613: Canopen-interface Typ Variotech ANTS CanOpen -protocol
encoder system : Connection on FKR-613: Canopen-interface Typ Variotech ANTS SAFE CanOpen -protocol
encoder system : Connection on FKR-613: Canopen-interface Typ ELGO LIMAX33CP SAFE CanOpen -protocol
encoder system : Connection on FKR-613: Canopen-interface Typ --- encoder CanOpen -protocol
