KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 192 -
E998 Priority Car Call Target Floor
Input of the target Floor
B73- Assignment ER - EAx
In this menu area, various functions can be assigned to the two inputs EA1 and EA2 of the floor com-
puter ER-2014, as well as to the serial external display computers SAT601 and SAT602. The assign-
ment of the functions only works in the configuration as a single driver.
The following functions are available:
Landing call preference Door1
or/& 2
The forced recovery modes described and set in menu item
B24, such as single, collective, single soft and single drain-
Call encryption, i.e. by pressing the outside call button, no exter-
nal call is made, but only by additional activation of the key
switch. By applying a control voltage of + 24V DC to an input
with input function E984 "External call encryption OFF", the ex-
ternal call encryption can be canceled.
By activating the parameter quiet motion in menu B608 and se-
lecting the corresponding settings, the car can be moved to a
rest plane and the control and the driving light can be switched
off by actuating the key switch at input EAx.
After leaving the shaft pit and closing the lower shaft door, a re-
set of the controller can be reset by operating the reset key but-
ton. Normal operation is possible again.
B74- PULSE BUFFER DELAY
Times for debouncing of entrances can be changed by this menu range. Following four ranges are
available:
1. Times for debouncing ZR. Default value for central processing unit amounts to 30 ms.
2. Times for debouncing FKR. Default value for car controler amounts to 30 ms.
3. Times for debouncing ER. Default value for remote station amounts to 30 ms.
4. Times for debouncing ZG. Default value for expansion unit amounts to 30 ms.
