KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 157 -
time. If the pressing switching off entrance becomes “LOW” ( negative pressure) then also switches off,
too. If the pressing switching off entrance is used then the follow-up time should be adjusted on approx
1-2 seconds ( functions then only as watchdog time).
With each start the elevator with retrieving speed drives to zone-ends upward. It is all the same whether
the goal stop is above or below the floor. The elevator stops there and the bolts drive in. Afterwards the
trip is started into the goal floor.
Elevator stands and there are calls in the system:
1) If bolt is outside then the door and DSK shift-ON -> Elevator drives 50mm high
2) Bolt is brought in
3) If BZ-ON, then DSK shift-ON and trip to next floor
4) If BZ-OFF the DSK shift –OFF and trip to next door
5) If bolts brought in and BZ-ON, then DSK shift and start
Elevator drives into floor and the bolts are into the shelter:
1) The elevator stops about the floor in a 50 mm distance, the door remains closed
2) The bolts drive out
1. 3) DSK Shift-OFF, elevator drives concisely, door opens
Safety notice – Disclaimer
If the car is in "Return Control" or "Inspection Control" operating modes, the bolts can be manually re-
tracted and retracted using the two E364 and E365 programmable input functions (see buttons on the
return control).
If the bolts have been extended manually and not retracted completely, it may happen that after
switching back to normal operating mode, the bolt limit switches are checked by extending and retract-
ing. However, as long as the bolt is not fully retracted, the car can not move.
B618 CODELOCK CALLS
Car Calls: In every Floor you can enter only four Number
(0-1-2-3-4-5-6-7-8-9 )
The code is entered with programable input function E334-E344. For the input of the code as the latter
“ #”-button is pressed. If the code was entered correctly an interior call is realeased to the appropriate
and one time pieco buzzer. If the wrong code was entered, so it beeps 3 times. By pressing the key
the place counter is increased. If longer than 5 seconds no pressing the key takes place or if the input
is pressed then the place counter is put back.
PARAMETER: CAR CALLS
With activated parameter can be specified for how much floors a coding is necessary.
PARAMETER: CODE INPUT FLOORS 01 UP TO MAX
With activated parameter a numeric code ( with four digits) for the car call can be deposited for each
floor.
The following Inputfunctions are needed:
