3. Menue Description
3.1 Menu- and Parameterstructure
A-LIFTPARAMETER
A1 Lift Description
Factory values
Elevator values
A1. Type
XXXXXXXXXX
A1.2 Lift No.
XXXXXXXXXX
A1.3 Controller No.
XXXXXXXXXX
A1.4 Place
XXXXXXXXXX
A1.5 Time/Date
xx:xx:xx xx.xx.xxxx
A1.5 a Summer/Winter
Time-shift: Automatic
Yes
A1.6 Language
German, English, Polnisch
English
A1.7 Display Line-1
XXXXXXXXXX
A1.8 Display Line-2
XXXXXXXXXX
A1.9 Software Version
D613-00.091
PIC 00.026
FKR613-00.000
MaintenanceLCD
ER-Bus-1
ER-Bus-2
ER-Bus-3
Expansion-Bus: ZG32 – module/
Sensor – module / Pit modul
ZG16 & RG12 modules
A1.10 Password
X X X X
A2 Controller
A2.1 Type of Drive
Scanclimber-Variable Frequency
Rope-Variable Frequency
X
Rope-Variable Voltage
Rope-2 speeds
Hydraulic-Variable Frequency
Hydraulic-Regulated
Hydraulic-Not Regulated
A2.2 Type of Controller
TAXI – Controlling
One Button exclusive
One Button deadman
Destination Control
Two Buttons- Destination Control
Pre-Selection Control
Two Buttons UP+DOWN
One Button UP+DOWN
One Button down coll.
X
One Button no coll.
Attendand Controlling
Send-Controlling
A2.3 Group
No, Yes
No
A2.4 No. Of Lifts
2 to 8 Lifts
2
A2.5 Group No.
1 to 8
1
A3 Shaft
A3.1 No. Of Floors
2 to 64
8
A3.2 Main Floor
1 to 64
2
A3.2 Main Floor 2
No, 1 to 64
No
A3.3 Lowest Floor
1,2,3,4,5,6,7,8
1
A3.4 Door Sides
1, 2, 3 Door Sides
1
A3.5 Shaft Copy
Floor without zone
LÖDIGE without zone
LÖDIGE with zone
R&S-Copy
Minimum Copy
Motor-Copy
Absolut-Copy
X
Relativ-Copy
Standart-copy
A3.6 Nominal speed
V-nominal 0,30 m/s – 8,00 m/s
1,00 m/s
