KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 129 -
B505- Gong at the Floor
Like the car controller unit FKR, also the remote station ER 2005 offers the possibility of activating the
gong function. You can attach a miniature speaker with an impedance of 8 ohms at the clamps 330 and
331 for the door side 1, as well as at the clamps 332 and 333 for the door side 2 of the FKR unit.
You can select between accord, two-sound and triad gong. Additionally, you can select a different
sound function for the up and downwards. The following trip modes can be switched on:
A) Car calls
B) Landing calls
C) Priority calls
D) Fire Fighter Service
E) Special trip
Gong Function
Here, you can select whether the floor gong is active.
Car Call UP
Here, it can be selected whether the floor gong is active on an internal call with direction of travel UP,
and the amount of gongs. The choice is balanced, double and triangle.
Car Call DOWN
Here, you can choose whether the floor gong is activated for an internal call with direction AB,
and the amount of gongs. The choice is balanced, double and triangle.
Landing Call UP
Here, you can choose whether the floor garnish is activated on an outside call with direction of travel
UP, and the amount of gongs. The choice is balanced, double and triangle.
Landing Call DOWN
Here, it can be selected whether the floor garnish is active on an exit call with direction AB,
and the amount of gongs . The choice is balanced, double and triangle.
Priority Call UP
Here, it can be selected whether the floor garnish is active on a priority call with direction of travel UP,
and the amount of gongs. The choice is balanced, double and triangle.
Priority Call DOWN
Here, it can be selected whether the floor garnish is activated by a priority call with direction AB,
and the amount of gongs. The choice is balanced, double and triangle.
Fire Fighter Service
Here, you can choose whether the floor gong is active on a fire fighter trip, and the amount of gongs.
The choice is balanced, double and triangle.
Special Trip
Here, you can choose whether the floor gong is active on a special trip, and the amount of gongs. The
choice is balanced, double and triangle.
Gong function – volume
Here the volume of the gong can be adjusted to the environment. The value range is from 1% to 100%.
The factory setting is 50%.
Gong function – pitch
Here the pitch of the gong can be adjusted to the environment. The value range is from 1% to 100%.
The factory setting is 50%.
OUTPUT ER GONG PULSE
Pulse length for gong impulse on ER adjustable: pulse, 1…10 seconds.
