KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 166 -
B7 Input/ Output
General
In- and Output-channels at the control system DAVID-613 are easily programmable, i. e. the entrances
are exits of the computer units ZR, ZG , FKR , EIT and ITR can be occupied freely with the most different
in and base functions. In order to not occupy this control system with also over 350 input- and otput
functions each channel separately, preemption frameworks were introduces which make a preempition
possible of the channels. Nevertheless each free-programable entrance and exit with another function
can be occupied. In the menu B73 I/O preemption, preemption frameworks are to you at the disposal.
A fundamental proceed is to be planned as follows:
1. In menu B73 I/O preemption selects after the needs fitting preemption-frame.
2. Afterwards the entrances and exits are adapted after the control needs. This happens in the
menus B71 preemption Outputs and B72 preemption Inputs.
B71 Allocation Outputs
The outputs ZR-, ZG-, FKR-, and ITR-unit can be occupied in principle with the functions specified down.
No function is assigned to the exit/relay.
The relay tightens during a door movement.
The relay tightens active function nudging with door latches.
The relay energizes emergency power evacuation or fire drop evacuation.
A04-CASE OF FIRE-EVACUATION
The relay energizes the case of fire evacuation.
The relay energizes the emergency power.
A06-FIRE-BRIGADE PRIORITY
The relay energizes the fire- brigade priority.
The relay energizes if the case of fire level is reached.
A08-EMERGENCY POWER LEVEL
The relay energizes if the emergency power level is reached.
The relay energizes if the fire brigade level is reached.
The relay falls if door fault is present.
The relax falls if out of operation is present.
The relay falls if motor temperature fault is present.
The relay falls if the motor temperature is present.
Output if inspection service is on.
Output if resent service is on.
Output if normal operation service is on.
Output if full load is on.
Output if overload is on.
Output if less load is on.
Output if preference inside is on.
Output if preference outside is on.
Output if preference total is on.
Output at activated motor fan function.
Output at activated car fan function.
Output at activated cabinet fan function.
Output entry signal ( Impuls 500ms).
Output door control door 1 open.
Output door control door 1 close.
Output door control door 2 open.
Output door control door 2 close.
Output of the message special trip.
Output of the message rescue trip.
Output of the message leader enterprise.
The relay energizes with expiration of the adjusted time in the parameter B12.
The relay energizes if at U 10 tension lies on. ( shaft door close)
The relay energizes if at U 11 tension lies on. ( car door close)
A41-out of operation invers
Output if the elevator is out of operation.
A42-collective fault invers
Expenditure, if the plant shows a collecting fault signal.
Expenditure to control of the protection circuit.
Expenditure if the parking level is reached.
A45 call messagering car fan
Expenditure call messaging at active car fan
