B506- LED-Matrix
The car panel pcb EIT and remote station ER-2007 have RJ-12 ( 10-pole socket strips) sockets for the
control of the matrix displays ANZ-22,-32, -33, -52 and 53.
FLOOR DISPLAY CAR & REMOTE STATION ER
For each stop a designation can be selected. The range of the letters and numbers is limited.
ARROR DISPLAY CAR
You can choose between:
- No (No expenditure for arrow)
Yes (Standing arrow)
- Scroll (Current arrow)
SEGMENTS CAR
Depending on the selected matrix unit it can be selected whether a 2 or 3 segment matrix display is
going to be used.
ARROR DISPLAY REMOTE STATION
You can choose between:
- No (No expenditure for arrow)
- Yes (Standing arrow)
- Scroll (Current arrow)
INDICATOR FIELD REMOTE STATION
Depending on the selected matrix unit an indicator field is present, which can be assigned for a type-
output.
SEGEMENTS REMOTE STATION
Depending upon selected matrix unit it can be selected whether a 2 or 3 segment matrix display is to be
headed for.
CENTRAL UNIT DISPLAY
You can choose between:
- Display 1 to 64
- Display as it is in the car
.
