KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 128 -
B504- Gong at the Car
In the first parameter of this menu you can activate the car gong function. You can attach a miniature
speaker with an impedance of 8 ohms at the clamps 330 and 331 for the door side 1, as well as at the
clamps 332 and 333 for the door side 2 of the FKR unit. You can select between accord, two-sound
and triad gong. Additionally you can select a different sound function for the up- and downwards. The
following trip modes can be switched on:
A) Car calls
B) Landing calls
C) Priority calls
D) Fire fighter service
E) Special trips
Gong Function
Here, you can select whether the floor gong is active.
Car Call UP
Here, it can be selected whether the floor gong is active on an internal call with direction of travel UP,
and the amount of gongs. The choice is balance, double and triangle.
Car Call DOWN
Here, you can choose whether the floor gong is activated for an internal call with direction AB,
and the amount of gongs. The choice is balance, double and triangle.
Landing Call UP
Here, you can choose whether the floor garnish is activated on an outside call with direction of travel
UP, and the amount of gongs. The choice is balance, double and triangle.
Landing Call DOWN
Here, it can be selected whether the floor garnish is active on an exit call with direction AB,
and the amount of gongs. The choice is balance, double and triangle.
Priority Call UP
Here, it can be selected whether the floor garnish is active on a priority call with direction of travel UP,
and the amount of gongs. The choice is balance, double and triangle.
Priority Call DOWN
Here, it can be selected whether the floor garnish is activated by a priority call with direction AB,
and the amount of gongs. The choice is balance, double and triangle.
Fire Fighter Service
Here, you can choose whether the floor gong is active on a fire fighter trip, and the amount of gongs.
The choice is balance, double and triangle.
Special Trip
Here, you can choose whether the floor gong is active on a special trip, and the amount of gongs. The
choice is balance, double and triangle.
Gong function – volume
Here, the volume of the gong can be adjusted to the environment. The value range is from 1% to 100%.
The factory setting is 50%.
Gong function – pitch
Here, the pitch of the gong can be adjusted to the environment. The value range is from 1% to 100%.
The factory setting is 50%.
