PARAMETER:CAR PANEL CONTROLLER
In this parameter you can indicate whether the selective car calls realize with one or two car controller
ITR. Up to 8 stops the realization you can use an car calling controller, and/or can alternatively second
car calling controller ITR.
PARAMETER: MISUSE PROTECTION
The car calls deletes with the next stop, if 2 following each stops no light barrier interruption takes
place.
PARAMETER: BUTTON BUZZER
In this parmeter you can indicate whether an accoustic messaging at the push button movement.
PARAMETER: CAR CALL RANGE
In this parameter the lift can be divided into two ranges, which will not leave by car calling.
PARAMETER: CAR CALL LIMIT
Car call border: > xx calls delete
Function: If elevator drive into the floor and more car calls indicated than in the parameter is set in,
then the car calls will be automically deleted.
Parameter: Automatic Carcall Vehicle
At carelevator with two stops, you can set the car calls automatically.
Parameter: Delete call with double-click
If the parameter is active, this call can be deleted by double-clicking on the already set indoor call but-
ton.
B22- Landing Calls
GENERAL
Since spring 2007 all controls are delivered with a remote station for the external control. According to
standard selective 2-KS control is present (2xA,2xB,2xC and 2xD), as well as further four in- and out-
put channels, which are free provable. Later you can realise functions like landing prioritys and other.
The advantage consists of the fact that practically no hardware re-tooling expenditure exists, since all
missing functions can be modulated by software.
Standard Setting: In- and Output channels at the Remotestations ER-2007 / 2009:
Term
Function at Terminal
Output Menu B71
Input Menu B72
2xA
Fix: Landing Call Up
2xB
Fix: Landing Call Down
2xC
Free programabel -> Standard: Landing Call Door 2 Up
A199 c. mess.-D2 Up
E248 l.call-D2 Up
2xD
Free programabel -> Standard: Landing Call Door 2 Down
A200 c.mess.-D2 Down
E249 l.call-D2 Up
97A
Free programabel -> Standard: Floor arrow Door side 1 Up
A201 ER Arrow D1 Up
E00 no function
98A
Free programabel -> Standard: Floor arrow Door side 1 Down
A202 ER Arrow D1 Down
E00 no function
97B
Free programabel -> Standard: Floor arrow Door side 2 Up
A203 ER Arrow D2 Up
E00 no function
98B
Free programabel -> Standard: Floor arrow Door side 2 Down
A203 ER Arrow D2 Down
E00 no function
RJ-12
KW-Bus-Matrix-indicator, free programable Characterset, Scroll of signs & arrows, A1
RJ-12
KW-Bus-Matrix-indicator, free programable Characterset, Scroll of signs & arrows, A2
PZ1
Piezo Bruzzer for doorside 1
PZ2
Piezo Bruzzer for doorside 2
In the use of remotestation ER-2005 there are more In- and output functions and floor gongs.
Specialparameterset: In- and Output at the Send-and Resend Controller:
Term
Function at Terminal
Output Menu B71
Input Menu B72
2xA
Fix: Landing Call Up
2xB
Fix: Landing Call Down
2xC
Free programabel -> Standard: Landing Call Door 2 Up
A199 c.mess.-T2 Up
E248 l.call-D2 Up
2xD
Free programabel -> Standard: Landing Call Door 2 Down
A200 c.mess.-T2 Down
E249 l.call-D2 Down
97A
Fix: Landing Call HS 01
98A
Fix: Landing Call HS 02
97B
Fix: Landing Call HS 03
98B
Fix: Landing Call HS 04
RJ-12
KW-Bus-Matrix-indicator, free programable Characterset, Scroll of signs & arrows, A1
RJ-12
KW-Bus-Matrix-indicator, free programable Characterset, Scroll of signs & arrows, A2
PZ1
Piezo Bruzzer for doorside 1
PZ2
Piezo Bruzzer for doorside 2
